SenseCAP Sensor Hub 4G Data Logger
SenseCAP Sensor Hub 4G Data Logger

SenseCAP Sensor Hub 4G Data Logger

Rechargeable Battery
£247.00
£247.00
Skip to product information
SenseCAP Sensor Hub 4G Data Logger
1/5
  • SenseCAP Sensor Hub 4G Data Logger
  • SenseCAP Sensor Hub 4G Data Logger
  • SenseCAP Sensor Hub 4G Data Logger
  • SenseCAP Sensor Hub 4G Data Logger
  • SenseCAP Sensor Hub 4G Data Logger
SenseCAP Sensor Hub 4G Data Logger

Features
  • Support collection of various environmental data simultaneously
  • Support local storage of data
  • Support using with standard MODBUS-RTU RS485 sensors
  • Support uploading data to any server (SenseCAP Server / User's private server)
  • Support 4G/3G/2G communication, supporting global LTE frequency band
  • Built-in GPS positioning function
  • Support remote upgrade and maintenance
  • Two power supply options available: DC only, Solar Power (to be purchased separately, coming soon)
  • Easy to install and deploy, without requirements of engineering background
  • Industry standards, suitable for harsh outdoor environments
Power Source
Backorder
£247.00
£247.00

Description

Sensor Hub Data Logger is an easy-to-deploy 4G cellular station. It uses the MODBUS-RTU RS485 protocol to communicate with sensors and is able to collect various sensor data simultaneously.

Sensor Hub consists of 4 RS485 data channels. With extension hubs / RS485 splitters, it can connect with a maximum of 32 sensors at one time. The data is collected and sent to the cloud (either to the SenseCAP server or the client's private server) via 4G/3G/2G.

Sensor Hub is available in two versions:

1) DC only Version(This version can work with a solar system. Please kindly note it should be connected with the whole solar system, not just a solar panel)

(2)With a built-in rechargeble battery version(This version can be used with either DC power, or with a solar panel (will be coming soon).

Designed with industry standards and IP66 rated, Sensor Hub is suitable for outdoor and harsh environments, resistant from UV, rain, and dust, etc. GNSS is embedded for location tracking.

Sensor Hub is also equipped with 10MB onboard memory, to store more than 700,000 measurements locally in case of a bad connection. For the version with a built-in rechargeable battery, the large-capacity lithium battery ensures the devices work for up to 2 weeks after a power outage or during rainy weather.
