MS48-LR/MS48-LR-EC25-E: LoRaWAN to Modbus Gateway

Features
  • Open source Debian system
  • Supports LoRaWAN basic station
  • Supports Semtech UDP packet forwarder
  • Supports Chirpstack-Gateway-Bridge (MQTT)
  • Built-in Chirpstack local LoRaWAN server
  • Built-in Node-Red local application server
  • Acts as Modbus Slave mode
  • Power Input: 12V, 2A, DC
  • Operating Temperature: -20~70°C
  • Optional 4G cellular connection
  • Managed by WebGUI, SSH via WAN or Wi-Fi
  • Auto-provisioning for batch deployment and management
  • 10 programmable parallel demodulation paths
  • Pre-configured to support different LoRaWAN regional settings
  • Supports customization of LoRaWAN regional parameters
Connection Method
1 left
£270.00
£270.00

Description

The MS48-LR is an open-source LoRaWAN To Modbus Gateway. It allows users to bridge a LoRa wireless network to an IP network via WiFi , Ethernet or Cellular Network (via Optional 4G module). The LoRa wireless allows users to send data over extremely long ranges at low data rates.

The MS48-LR is fully compatible with the LoRaWAN protocol. MS48-LR includes a built-in LoRaWAN Server and IoT server. Users can connect various LoRaWAN devices to the MS48-LR, and use PLC to access these devices via Modbus network.

Different countries use different LoRaWAN frequency bands- the MS48-LR has these bands pre-configured. Users can also customize the frequency bands to use in their own LoRa network.

The MS48-LR supports remote management. Systems integrators can easily remotely monitor the gateway and maintain it.
