D20S-NX: NB-IoT Buried Type Outdoor Temperature Sensor

Features

Measurement range: -55°c ~ 125°c
Accuracy: ±0.5°c (max ±2.0°c)
Supports temperature alarm feature
Ultra-low power consumption
Supports Bluetooth v5.1 remote configuration
Supports OTA firmware updates
Uplinks periodically
Downlink to change parameters

Backorder

£79.00

Description

The Dragino D20S-NX is a NB-IoT Buried Type Temperature Sensor for Internet of Things solutions. The D20S-NX will convert the temperature reading to upload the sensor data to an IoT platform via the NB-IoT network.

The temperature sensor used in D20S-NX can measure -55°C ~ 125°C with an accuracy of ±0.5°C (max ±2.0 °C).

The D20S-NX supports the temperature alarm feature. Users can set the temperature alarm for instant notice. The D20S-NX supports the datalog feature, it can log the data when there is no NB-IoT network connection and uplink this data when network recovers.

The D20S-NX supports different uplink methods including MQTT, MQTTs, UDP & TCP for different application requirements, and supports uplinks to various IoT Servers.

The D20S-NX supports BLE configuration and OTA updates which makes the device easy to use.

The D20S-NX is powered by 8500mAh or 190000mAh Li-SOCI2 battery or solar powered with a 3000mAh Li-ion battery designed for long term use.
